Nickel Alloy Inconel 718 UNS N07718
HY 718 相似牌号
HY 718 / GB GH4169 / UNS N07718 / SEW VDIUV W.Nr.2.4668 NiCr19Fe19Nb5Mo3 / BS NA 51 / AFNOR NC19FeNb
HY 718 的化学成分:
合金 |
% |
镍 |
铬 |
铁 |
钼 |
铌 |
钴 |
碳 |
锰 |
硅 |
硫 |
铜 |
铝 |
钛 |
718 |
最小 |
50 |
17 |
余量 |
2.8 |
4.75 |
0.2 |
0.7 |
||||||
最大 |
55 |
21 |
3.3 |
5.5 |
1 |
0.08 |
0.35 |
0.35 |
0.01 |
0.3 |
0.8 |
1.15 |
HY 718 的物理性能:
密度 |
8.2 g/cm3 |
熔点 |
1260-1340 ℃ |
HY 718 在常温下合金的机械性能的最小值:
合金 |
抗拉强度 |
屈服强度 |
延伸率 |
布氏硬度 HB |
固溶处理 |
965 |
550 |
30 |
≤363 |
HY718合金具有以下特性:
1.易加工性
2.在700℃时具有高的抗拉强度、疲劳强度、抗蠕变强度和断裂强度
3.在1000℃时具有高抗氧化性
4.在低温下具有稳定的化学性能
5.良好的焊接性能
HY 718 的金相结构:
718合金为奥氏体结构,沉淀硬化后生成的γ”相使之具有了优秀的机械性能。在热处理过程中于晶界处生成的δ相使之具有了最佳的塑性。
HY 718 的耐腐蚀性:
不管在高温还是低温环境,718合金都具有极好的耐应力腐蚀开裂和点蚀的能力。718合金在高温下的抗氧化性尤其出色。
HY 718 应用范围应用领域有:
由于在700℃时具有高温强度和优秀的耐腐蚀性能、易加工性,718可广泛应用于各种高要求的场合。
1.汽轮机
2.液体燃料火箭
3.低温工程
4.酸性环境
5.核工程
生产标准:
板材 |
AMS 5599/AMS 5879/ASME SB-443 Gr. 1/ASTM B-443 Gr. 1 |
棒材;锻件 |
AMS 5666/ASME SB-446 Gr. 1/ASTM B-446 Gr. 1 |
各类合金的常用规格 | |||
Form | Specification | Supply Form | Others |
Sheet | Thickness:0.40-4.75mm,General Width:1000、1219、1500mm | Whole Coil or piece of it | Cold Annealed,Surface 2B、2E |
Plate | Thickness:4.76-60mm,Width:1500、2000、2500mm,Length:3000、6000、8000、8500mm(Under 10mm plate can be coiled) | Whole Coil or piece of it | Single hot rolling,Solid solution annealed state,Surface 1D |
Belt | Thickness:0.10-3.0mm,Width:50-500mm | Whole Coil or Specified size | Cold Annealed,Surface 2B、2E |
Bar & Rod | Rolled barΦ5-45mm,Length≤1500mm | Polished Bar(circle、Square) | Solution annealing,descaling |
Forged barΦ26-245mm,Length≤4000mm | |||
Weld tube | Outer diameterΦ4.76-135mm,Wall Thickness0.25-4.00mm,Length:≤35000 mm | Base on your requirement | |
Seamless Tube | Outer diameterΦ3-114mm,Wall Thickness0.2-4.5mm | Base on your requirement | |
Wire | Outer diameterΦ0.1-13mm | Base on your requirement | Ni & Ni alloy, Ti & Ti alloy |
Forged piece | discs,rings,squares,blocks,slabs | Base on your requirement | Steel, Alloy |
Flangs | All kinds of Flangs | Base on your requirement | Steel, Alloy |
Welding Material | Coil wire Φ0.025mm-1.6mm | Base on your requirement | Certificate of Origin:America, Sweden, Britain, Germany, Austria, Italy, France. |
Straight WireΦ1.6mm-4.0mm | |||
Welding rodΦ1.2mm-4.0mm | |||
Tube | Elbow, three links, four links, different diameter size | Base on your requirement | Ni & Ni alloy, Ti & Ti alloy |
Explosive bonded laminate | Raw Sheet Thickness≥2mm | Base on your requirement | Ni & Ni alloy, Ti & Ti alloy |
