Nickel Alloy Inconel X-750 UNS N07750
HY X-750 相似牌号:
Inconel X-750 / GB GH4145 / UNS N07750/W.Nr.2.4669 NiCr15Fe7TiAl / AFNOR NC15FeT
HY X-750的化学成分:
合金 |
% |
镍 |
铬 |
铁 |
铌 |
钴 |
碳 |
锰 |
硅 |
硫 |
铜 |
铝 |
钛 |
GH4145 |
最小 |
14 |
5.0 |
0.7 |
0.4 |
2.25 |
|||||||
最大 |
70 |
17 |
9.0 |
1.2 |
1.00 |
0.08 |
1.00 |
0.5 |
0.01 |
0.5 |
1.0 |
2.75 |
HY X-750 的物理性能:
密度 |
8.28 g/cm3 |
熔点 |
1393-1427℃ |
HY X-750 在常温下合金的机械性能的最小值:
合金 |
抗拉强度 |
屈服强度 |
延伸率 |
布氏硬度 HB |
固溶处理 |
1267 |
868 |
25 |
≤400 |
HY X-750合金具有以下特性:
HY X-750 在980℃以下具有良好的耐腐蚀和抗氧化性能,800℃以下具有较高的强度,540℃以下具有较好的耐松弛性能,同时还具有良好的成形性能和焊接性能,在低温环境中有优异的机械性能。
HY X-750 应用范围应用领域有:
该合金在高温环境下具有良好的耐蚀性和蠕变断裂强度,力学性能好,应用十分广泛, 980℃以下有足够的强度及抗腐蚀抗氧化性 .
1. 制造高温下工作的弹簧,螺栓; 燃气涡轮机上的转子叶片 ,叶轮和其它结构件 ;
2. 火箭发动机上的推力室;
3. 飞机上的反推力装置;
4. 大型的高压容器;
5. 弹性气封片,弹性密封模片 ,橡胶机械电热刀片。
生产标准:
板材 |
AMS 5542/ASM 5598/Mil-N-7786 |
锻件 |
AMS 5667/AMS 5668/AMS 5669/AMS 5670/AMS 5747/AMS B-637 |
各类合金的常用规格 | |||
Form | Specification | Supply Form | Others |
Sheet | Thickness:0.40-4.75mm,General Width:1000、1219、1500mm | Whole Coil or piece of it | Cold Annealed,Surface 2B、2E |
Plate | Thickness:4.76-60mm,Width:1500、2000、2500mm,Length:3000、6000、8000、8500mm(Under 10mm plate can be coiled) | Whole Coil or piece of it | Single hot rolling,Solid solution annealed state,Surface 1D |
Belt | Thickness:0.10-3.0mm,Width:50-500mm | Whole Coil or Specified size | Cold Annealed,Surface 2B、2E |
Bar & Rod | Rolled barΦ5-45mm,Length≤1500mm | Polished Bar(circle、Square) | Solution annealing,descaling |
Forged barΦ26-245mm,Length≤4000mm | |||
Weld tube | Outer diameterΦ4.76-135mm,Wall Thickness0.25-4.00mm,Length:≤35000 mm | Base on your requirement | |
Seamless Tube | Outer diameterΦ3-114mm,Wall Thickness0.2-4.5mm | Base on your requirement | |
Wire | Outer diameterΦ0.1-13mm | Base on your requirement | Ni & Ni alloy, Ti & Ti alloy |
Forged piece | discs,rings,squares,blocks,slabs | Base on your requirement | Steel, Alloy |
Flangs | All kinds of Flangs | Base on your requirement | Steel, Alloy |
Welding Material | Coil wire Φ0.025mm-1.6mm | Base on your requirement | Certificate of Origin:America, Sweden, Britain, Germany, Austria, Italy, France. |
Straight WireΦ1.6mm-4.0mm | |||
Welding rodΦ1.2mm-4.0mm | |||
Tube | Elbow, three links, four links, different diameter size | Base on your requirement | Ni & Ni alloy, Ti & Ti alloy |
Explosive bonded laminate | Raw Sheet Thickness≥2mm | Base on your requirement | Ni & Ni alloy, Ti & Ti alloy |
